5 Inch LCD Screen TFT LCD Display 720*1080 IPS Panel RGB 300 Nits

The LTK050HDHLM13-V0 is a 5.0-inch IPS LCD module designed for industrial applications, delivering sharp HD (720×1280) resolution with wide viewing angles and consistent color performance. With a 300 cd/m² high-brightness display and an RGB/MIPI interface, it ensures reliable visibility and flexible integration in smart industrial equipment. The compact 65.3×119.3×1.7mm design houses an active area of 62.1×110.4mm, while its -10°C to +60°C operating range and NV3052CGRB driver IC provide stability in harsh environments. Suitable for HMIs, control panels, and IoT devices, it balances durability and high-quality display performance for industrial automation solutions.

Inquire Now

BackPrevious Next

Product Details

Part Number.	LTK050HDHLM13-V0
Size(inch)	5.0
Display Mode	IPS
Resolution	720*1280
Interface	RGB
ExpandableInterface	MIPI
Luminance (cd/m²)	300
Driver IC	NV3052CGRB
Active Area (mm)	62.10*110.40
Outline Dimension (mm)	65.30119.301.70
Operating Temp	-10~+60℃
Storage Temp	-20~+70℃
