4.3 Inch 480x800 MIPI TFT Module with High Brightness 1000nits
LTK043FTBLM41-V0 is a 4.3-inch IPS TFT LCD module featuring 480×800 high resolution and 1000 cd/m² ultra-high brightness, ensuring clear and sharp image performance even in strong ambient light. Features a vertical screen design with MIPI interface and expandable RGB/SPI interfaces, providing flexible integration for different system architectures. The IPS technology offers wide viewing angles and stable color performance, making it suitable for compact HMI and high-visibility display designs in smart home products.Designed for smart home applications, it is ideal for smart control panels and related indoor intelligent display terminals.
- Product Details
|
Part Number |
LTK043FTBLM41-V0 |
| Size(inch) | 4.3 |
|
Display Mode |
IPS |
|
Resolution |
480*800 |
|
Interface |
MIPI |
| Expandable Interfaces | RGB/SPI |
|
Luminance (cd/m²) |
1000 |
|
Active Area(mm) |
56.16(W)*93.60(L) |
|
Outline Dimension(mm) |
60.00(W)*101.80(L)*1.68(T) |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
