10.1 Inch High-Brightness Portrait IPS TDDI TFT LCD Display Module
LTK101FTNIT78-V0 is a 10.1-inch IPS TFT LCD display module featuring a 1200×1920 high resolution, 500 cd/m² brightness, and wide viewing angles for clear and vibrant image quality. Integrated withMIPI TDDI (Touch and Display Driver Integration)technology, the module helps reduce system complexity, lower power consumption, and support a slimmer device design. With its reliable performance and industrial-grade display quality, it is an ideal solution for smart industrial equipment, HMI systems, control panels, and intelligent automation applications.
- Product Details
|
Part Number |
LTK101FTNIT78-V0 |
| Size(inch) | 10.10 |
|
Display Mode |
IPS |
|
Resolution |
1200*1920 |
|
Interface |
MIPI_TDDI |
|
Luminance (cd/m²) |
500 |
| Touch Screen | NA |
| TP Structure | NA |
| TP Interface | IIC |
|
Active Area(mm) |
135.36(H)*216.58(V) |
|
Outline Dimension(mm) |
148.80(H)*239.37(V)*3.58(T) |
|
Operating Temp |
-10~+60℃ |
|
Storage Temp |
-20~+70℃ |
