8.0-inch 1024×768 IPS High Brightness LVDS TFT LCD Display
The LTK080FTBLM34-V0 is an 8.0-inch IPS TFT LCD display featuring 1024 × 768 (XGA) resolution, a 950 cd/m² high-brightness backlight, and an LVDS interface. Designed for embedded applications requiring excellent visibility and reliable performance, it delivers wide viewing angles, 16.7 million colors, and stable image quality. Operating from -20°C to +70°C, it is well suited for smart home control panels, medical devices, and other industrial embedded systems requiring dependable long-term operation.
- Product Details
| Part Number. |
LTK080FTBLM34-V0 |
|
Display Mode |
IPS |
|
Resolution |
1024*768 |
|
Interface |
LVDS |
|
Brightness(cd/m²) |
950 |
|
Active Area(mm) |
162.06*122.97 |
|
Outline Dimension(mm) |
182.90*141.00*5.20 |
| Touch Screen | NA |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
