19.0-inch IPS LVDS TFT LCD Module with G+G Capacitive Touch

The LTK190FTBCT12-V1 is a 19.0-inch TFT LCD module featuring 1280 × 1024 resolution, IPS wide viewing angle, and 300 cd/m² brightness for clear and stable image performance. Equipped with an LVDS interface and G+G capacitive touch (CTP) powered by the ILI2510P touch controller, it delivers responsive and reliable touch interaction. Designed for demanding embedded applications, this display is well suited for smart medical equipment and smart transportation systems, including medical terminals, diagnostic devices, ticketing kiosks, passenger information systems, and industrial HMI applications.

Inquire Now

BackPrevious Next

Product Details

Part Number	LTK190FTBCT12-V1
Size(inch)	19.0
Viewing Direction	IPS
Resolution	1280*1024
Interface	LVDS
Luminance (cd/m²)	300
Active Area(mm)	374.78(H)*299.83(V)
Outline Dimension(mm)	419.48(H)344.42(V)16.9(T)
Touch Screen	CTP
TP Structure	GG
TP Interface	IIC
Touch Screen IC	ILI2510P
Operating Temp	-0~+50℃
Storage Temp	-20~+60℃
