13.3 Inch Full HD 430nits IPS TFT Display with eDP Interface
LTK133FTBGT23-V0 is a 13.3-inch Full HD IPS LCD display module featuring a high-speed eDP interface, delivering 1920×1080 resolution and 430 cd/m² brightness for clear, detailed, and stable visual performance.With its wide-viewing-angle IPS panel design, this display is ideal for smart industrial equipment and smart home applications, providing reliable operation, long-term stability, and an enhanced visual experience.
- Product Details
|
Part Number |
LTK133FTBGT23-V0 |
| Size(inch) | 13.30 |
|
Display Mode |
IPS |
|
Resolution |
1920*1080 |
|
Interface |
eDP |
|
Luminance (cd/m²) |
430 |
|
Active Area(mm) |
293.76(W)*165.24(L) |
|
Outline Dimension(mm) |
359.00(W)*240.00(L)*7.70(T) |
| Touch Screen | NA |
| TP Structure | GG |
|
Operating Temp |
-0~+50℃ |
|
Storage Temp |
-20~+60℃ |
Get A Quote
If you are interested in our products and want to know more details. please leave a message here. we will reply you as soon as we can.
