6.1 Inch Bar-Type Dual-Screen Stitched IPS TFT Touch Display with MIPI Interface
LTK061FTBCT12-V1 is an innovative ultra-wide touch display module featuring two 6.1-inch IPS TFT LCD panels stitched together in an inverted configuration, creating a unique elongated display format. With a resolution of 280×1424, 600 cd/m² brightness, IPS wide-viewing-angle technology, and integrated capacitive touch functionality, it delivers excellent visual performance and responsive user interaction. Equipped with MIPI display and IIC touch interfaces, this module is ideal for applications in smart home devices, automotive displays, and commercial display systems.
- Product Details
|
Part Number |
LTK061FTBCT12-V1 |
| Size(inch) | 6.10 |
|
Display Mode |
IPS |
|
Resolution |
280*1424 |
|
Interface |
MIPI |
|
Luminance (cd/m²) |
600 |
| Touch Screen | CTP |
| TP Structure | GFF |
| TP Interface | IIC |
|
Active Area(mm) |
29.99(H)*152.51(V) |
|
Outline Dimension(mm) |
250.00(H)*39.00(V)*2.20(T) |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
