13.3-inch Full HD IPS High Brightness eDP TFT LCD Module
The LTK133FTBLM23-V0 is a 13.3-inch transmissive TFT LCD module featuring Full HD (1920 × 1080) resolution, IPS wide viewing angle, and 500 cd/m² brightness for sharp, vibrant visuals. Equipped with an eDP interface, it provides high-speed data transmission and seamless integration into modern embedded systems. Designed for smart industrial and smart home applications, this display is well suited for industrial control panels, HMI terminals, smart home control centers, and intelligent automation equipment, delivering reliable performance and excellent image quality.
- Product Details
|
Part Number |
LTK133FTBLM23-V0 |
| Size(inch) | 13.3 |
|
Display Mode |
IPS |
|
Resolution |
1920*1280 |
|
Interface |
eDP |
|
Luminance (cd/m²) |
500 |
|
Active Area(mm) |
293.76(H)*165.24(V) |
|
Outline Dimension(mm) |
307.60(H)*183.05(V)*5.50(T) |
|
Operating Temp |
0~+50℃ |
|
Storage Temp |
-20~+60℃ |
