5.0 inch 720*1280 High Brightness TDDI TFT Display with MIPI Interface
The LTK050FTBIT47-V0 is a 5.0-inch TDDI color display module designed for modern smart applications. Featuring a MIPI interface and IPS technology, it ensures stable performance and wide viewing consistency. With a brightness of 500 cd/m², it is suitable for both indoor and semi-outdoor environments. Its compact structure and robust design support reliable operation across a wide temperature range from -20°C to +70°C.This module is ideal for smart transportation and smart home solutions, including applications such as smart door locks and home monitoring systems, offering a dependable and efficient display solution for next-generation devices.
- Product Details
| Part Number |
LTK050FTBIT47-V0 |
| Size(inch) |
5.0 |
|
Display Mode |
IPS |
|
Resolution |
720*1280 |
|
Interface |
MIPI |
|
Luminance (cd/m²) |
500 |
|
Active Area(mm) |
62.18(W)×110.22(L) |
|
Outline Dimension(mm) |
98.70(W)176.00(L)*3.09(T) |
| CTP Driver IC | ST7123 |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
Get A Quote
