Leadtek self-developed products 5 Inch 800*480 Transflective Display
The LTK050WVHCT20-V1 is a 5-inch transflective display that is ideal for intelligent transportation applications. It has a resolution of 800x480, provides clear and detailed visuals through an RGB interface, and supports 16.7 million colors. The reflectivity is 12.5% and the brightness reaches 70 cd/m . The active area size is 108.00*64.80 mm, while the overall size is 143.60*95.70*4.70 mm. This display also has a capacitive touch screen (CTP) for smooth and responsive touch interaction.
- Product Details
PRODUCT PARAMETER
| Size (inch) | 5.0 |
| Part Number. | LTK050WVHCT20-V1 |
| Display Type | Transflective |
| Resolution | 800*480 |
| Viewing Angle |
60/60/55/55 |
| Interface | RGB |
|
Luminance (cd/m²) |
70 |
| Color | 16.7M, full color |
| Reflectivity | 12.5% |
| Power Consumption (mW) | 1080 |
| Active Area (mm) |
108.00*64.80 |
| Outline Dimension (mm) | 143.60*95.70*4.70 |
| Touch Screen | CTP |
| TP Structure |
G+G |
| TP IC Model |
FT5426 |
| TP Interface |
IIC |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
