3.7-inch MIPI Transflective TFT LCD Module for Smart Home Devices

The LTK037BFBLM12-V0 is a 3.7-inch transflective TFT LCD module designed for smart home and embedded applications that require excellent visibility in both bright ambient light and low-light environments. Featuring a 480 × 854 resolution, MIPI interface, and 16.7 million full-color display, it delivers clear and vibrant images while maintaining low power consumption. The transflective technology utilizes ambient light to enhance outdoor readability while providing reliable backlight performance indoors, making it an ideal solution for smart home control panels, home automation systems, thermostats, and other energy-efficient HMI devices.

Inquire Now

BackPrevious Next

Product Details

Part Number	LTK037BFBLM12-V0
Size(inch)	3.7
Display Type	Transflective
Resolution	480*854
Luminance (cd/m²)	100
Viewing Angle	60/60/60/60
Interface	MIPI
Display colors	16.7M,full color
Reflective CR	7:1
Transmissive CR	80:1
Reflectivity	3.50%
Power Consumption(mW)	0.540
Active Area (mm)	46.08(H)*81.98(V)
LCM Module Size (mm)	49.56(H)89.37(V)2.08(T)
Operating Temperature	-20~+70℃
Storage temperature	-30~+80℃
