3.7 Inch 480x854 Full Color Transflective Display with MIPI Interface

The LTK037BFBCT12-V0 is a 3.7-inch transflective display module designed for energy-efficient and versatile applications. Combining reflective and transmissive modes, it maintains readability under both ambient light and low-light conditions. Featuring IPS technology and a MIPI interface, it ensures stable performance and consistent viewing quality. Its ultra-low power consumption of 0.540 mW makes it ideal for battery-powered devices. The integrated capacitive touch panel (CTP) with IIC interface enhances user interaction. With a wide operating temperature range of -20°C to +70°C, this module is well-suited for smart home, industrial, and intelligent transportation applications.

Inquire Now

BackPrevious Next

Product Details

Size(inch)	3.7
Part Number.	LTK037BFBCT12-V0
Display Type	Transflective
Resolution	480*854
Luminance (cd/m²)	60
Viewing Angle	60/60/60/60
Interface	MIPI
Display colors	16.7M,full color
Reflective CR	7:1
Transmissive CR	80:1
Reflectivity	3.50%
Power Consumption(mW)	0.540
Driver IC	ST7701SI-G5
Active Area (mm)	46.08(H)*81.98(V)
LCM+CTP Module Size (mm)	66.68(H)102.58(V)3.83(T)
Touch screen	CTP
TP Structure	G+FF
TP Interface	IIC
Operating Temperature	-20~+70℃
Storage temperature	-30~+80℃
