2.98 Inch 480*854 IPS Full Color Transflective Display with Touch

This 2.98-inch TFT LCD module features a 480×854 high-resolution display with vivid full-color performance and low power consumption. Designed with a capacitive touch panel and MCU/SPI interface, it offers smooth touch control and easy integration.With reflective/transmissive display technology, it provides clear visibility in different lighting conditions, making it ideal for smart home applications such as smart door locks, home security systems, and intelligent control panels.

Inquire Now

BackPrevious Next

Product Details

Size(inch)	2.98
Part Number	LTK030BFBCT12-V0
Display Type	Transflective
Resolution	480*854
Luminance (cd/m²)	85
Viewing Angle	60/60/60/60
Interface	MCU/SPI
Display colors	16.7M,full color
Reflective CR	85:10
Transmissive CR	80:1
Reflectivity	6.00%
Power Consumption(mW)	0.420
Active Area (mm)	38.88(H)*64.8(V)
LCM+CTP Module Size (mm)	59.38(H)85.30(V)2.96(T)
Touch screen	CTP
TP Structure	G+FF
TP Interface	IIC
Operating Temperature	-20~+70℃
Storage temperature	-30~+80℃
