10.1 inch 1920*1200 TFT LCD Module with High Brightness 1000nits

The LTK101WUBLM20-V0 is a 10.1-inch IPS display with a high resolution of 1920x1200 and exceptional 1000 cd/㎡ brightness, ideal for high-visibility smart industrial applications. Designed for harsh environments, it supports glove and wet-hand touch, ensuring accurate operation in factory and outdoor settings. The touch screen feature santi-static protection and robust durability, meeting the demands of electrically noisy and rugged conditions. With 16.7M color depth (8-bit) and a wide operating temperature range of-20°C to +70°C, it delivers vivid visuals and stable performance. The LVDS interface ensures reliable data transmission for embedded and automation systems.
  • Product Details

Size(inch) 10.1
Mode LTK101WUBLM20-V0
Display Mode
IPS
Resolution
1920*1200
Interface
LVDS
Brightness
1000 cd/㎡
Display Colors
16.7M(8bit )
Active Area(mm)
216.81×135.50
Outline Dimension(mm)
229.46×149.10×4.40
TFT Driver IC
TBD
Operating Temp
-20~+70℃
Storage Temp
-30~+80℃
