7.84" IPS 400x1280 Resolution TFT LCD Module
The LTK078WXBLM02-V0 is a 7.84-inch IPS display designed to bring vibrant visuals and reliable performance to smart home applications. With a crisp resolution of 400 x 1280, a brightness of 500 cd/m², and wide viewing angles thanks to IPS technology, it delivers clear, consistent images perfect for home control panels and automation systems. The active area measures 59.40 x 190.08 mm, Featuring a MIPI interface for fast, stable connectivity, this display also boasts a storage range of -30°C to +80°C, ensuring reliable performance in various home environments.
- Product Details
| Size (inch) | 7.84 |
| Part Number. | LTK078WXBLM02-V0 |
| Display Mode | IPS |
| Resolution | 400*1280 |
| Interface | MIPI |
| Luminance (cd/m²) | 500 |
| Active Area (mm) | 59.40*190.08 |
| LCM Outline Dimension (mm) | 67.80*206.18*4.66 |
| Operating Temp | -20°C~+70°C |
| Storage Temp | -30°C~+80°C |
Get A Quote
If you are interested in our products and want to know more details. please leave a message here. we will reply you as soon as we can.
