15.6 inch 1920*1080 TFT LCD Touch Screen Display with High Brightness
The 15.6" LTK156FTBCT27-V0 display offers Full HD resolution (1920x1080) with 600 cd/m² brightness, delivering vibrant visuals in industrial environments. Featuring a G+G touch panel and IIC+USB interface, it ensures responsive touch performance. With an operating range of -20°C to +70°C, this durable display is ideal for demanding smart industrial applications.
Its compact size and robust design make it perfect for integration into a wide variety of industrial equipment, providing both reliability and ease of use. The advanced touch technology further enhances interaction in mission-critical operations.
- Product Details
Size(inch) | 15.6 |
Part Number. |
LTK156FTBCT27-V0 |
Display Mode |
IPS |
Resolution |
1920*1080 |
Colors | 16.7M |
Interface |
2 lane eDP |
Luminance (cd/m²) |
600 |
Active Area (mm) |
344.16(W)×193.59(H) |
CTP+LCM Outline Dimension (mm) |
386.80(W)×236.07(H)×9.40(T) |
Touch screen | CTP |
TP Structure | G+G |
TP Interface |
IIC+USB |
Operating Temp |
-20~+70℃ |
Storage Temp |
-30~+80℃ |
