8.8 Inch 480*1920 Bar Type TFT LCD Module with 1000Nits for Smart Home

The LTK088FHHLM01-V0 is an 8.88-inch bar-type IPS TFT display designed for modern home and smart appliance applications. Featuring an ultra-wide resolution of 480×1920 and 16.7M colors, it delivers crisp and vivid visuals. Its high brightness of 1000 cd/m² ensures excellent readability in bright indoor or semi-outdoor environments. The display integrates the OTA7290 driver IC and supports a MIPI interface for fast, reliable communication. With a slim profile (64.0×231.10×4.60 mm) and a wide temperature tolerance (-30°C to +85°C), it is ideal for smart control panels, kitchen displays, and home automation systems.

Inquire Now

Back Next

Product Details

Size(inch）	8.88''
Part Number.	LTK088FHHLM01-V0
Display Mode	IPS
Color	16.7M
Resolution	480*1920
Interface	MIPI
Luminance (cd/m²)	1000
Drive IC	OTA7290
Active Area(mm)	54.72* 218.88
Outline Dimension(mm)	64.0231.104.60
Operating Temp	-30~+85℃
Storage Temp	-40~+90℃
