15.6" Full HD High Brightness IPS Rugged Display for Smart Transportation

The LTK156FTVLM30-V0 is a 15.6-inch rugged IPS TFT LCD display featuring a 1920×1080 Full HD resolution, 1000 cd/m² brightness, and wide viewing angles for clear images in bright environments. Equipped with an LVDS interface and an optional eDP interface, it offers flexible integration into transportation systems. Its rugged design and wide operating temperature range of -30°C to +85°C make it suitable for vehicle terminals, transportation monitoring systems, and passenger information displays.

Inquire Now

BackPrevious

Product Details

Part Number	LTK156FTVLM30-V0
Size(inch)	15.6
Display Mode	IPS
Resolution	1920*1080
Interface	LVDS
Expandable Interface	eDP
Luminance (cd/m²)	1000
Active Area(mm)	344.16(H)*193.59(V)
Outline Dimension(mm)	363.90(H)215.96(V)6.80(T)
Touch Screen	NA
Operating Temp	-30~+85℃
Storage Temp	-30~+85℃
