10.1 inch 1024*600 IPS Rugged Display for Military & Defense
This LTK101FTNLM54-V0 IPS LCD module features a high-resolution display of 1024*600 pixels, operates via an LVDS interface, and has a brightness of 850cd/m². The active area is 222.72*125.28mm, and the overall size is 235*143*5.12 mm. It can operate and store reliably in a temperature range of -30℃ to +85℃. It is ideally suited for smart industrial environments, providing clear, high-quality visuals and reliable performance under a variety of conditions.
- Product Details
|
Part Number |
LTK101FTNLM54-V0 |
|
Display Mode |
IPS |
|
Resolution |
1024*600 |
| Interface | LVDS |
|
Display Mode |
Normally Black |
|
Viewing Direction |
ALL |
|
Luminance (cd/m²) |
850 |
|
Active Area (mm) |
222.72*125.28 |
|
Outline Dimension (mm) |
235*143*5.12 |
|
perating Temp |
-30~+85℃ |
|
Storage Temp |
-30~+85℃ |
