3.9 inch LCD screen, resolution 480*128 420 brightness 40PIN RGB
Featuring a high-resolution IPS LCD module, the 3.9-inch LTK039MNBCT11-V0 delivers a sharp 480*128 pixel display with an brightness of 420.0 cd/m². Designed with an RGB interface, it offers an active area of 95.04*25.34 mm within an overall dimension of 103.20*34.85*2.50 mm. Equipped with capacitive touch panel (CTP) technology, it operates reliably across a wide temperature range from -20℃ to +70℃ and can be stored from -30℃ to +80℃. Ideal for smart home applications, this module ensures clear, high-quality visuals and stable performance in various environmental conditions.
- Product Details
| Size (inch) | 3.9 |
| Part Number. | LTK039MNBCT11-V0 |
| Display Mode | IPS |
| Resolution | 480*128 |
| Interface | RGB |
| Luminance (cd/m²) | 420 |
|
Module IC Model |
ST7282A |
| Active Area (mm) | 95.04*25.34 |
| Outline Dimension (mm) | 113.20*40.85*4.15 |
| Touch Screen | CTP |
| TP Sstructure |
GG |
|
TP IC model |
GT911 |
| TP Interface |
IIC |
| Operating Temp | -20~+70℃ |
| Storage Temp | -30~+80℃ |
