23.8 inch 1920*1080 IPS Panel, full color Reflective Display
Leadtek Display model LTK238PDHLM11-V0 is a BWR active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device.
It is a fully reflective display. This TFT LCD has a 23.8-inch diagonal active display area, a resolution of 1920 horizontal x 1080 vertical pixels, and dimensions of 532.54*302.86*1.30mm.
It is a fully reflective display. This TFT LCD has a 23.8-inch diagonal active display area, a resolution of 1920 horizontal x 1080 vertical pixels, and dimensions of 532.54*302.86*1.30mm.
- Product Details
|
Part Number |
LTK238PDHLM11-V0 |
|
Display Mode |
Reflective |
|
Resolution |
1920*1080 |
| Color |
16.7M, full color |
| Viewing Angle |
60/60/60/60 |
|
Reflectivity |
19.64% |
|
Reflection Contrast |
15:1 |
|
Power consumption |
1905/mW |
|
Active Area (mm) |
527.04*296.46 |
|
Outline Dimension (mm) |
532.54*302.86*1.30 |
| Interface | LVDS |
|
Operating Temperature |
-20~+60℃ |
|
Storage Temperature |
-30~+70℃ |
