11.6 Inch 1920*1080 HDMI Display with Touchscreen
The 11.6-inch LEADTEK display model LTK116FHBHT01-V0 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with IPS full viewing angle, a resolution of 1920*1080, and a brightness of 300cd/m2. It has a CTP touch screen and is equipped with an HDMI interface, supports 12V/3A voltage, and has an operating temperature of -20~+70℃, which is very suitable for smart industry and brings stable performance.
- Product Details
|
Model number |
LTK116FHBHT01-V0 |
|
Resolution |
1920*1080 |
|
Viewing Direction |
IPS |
|
LCM A.A (mm) |
256.32*144.18 |
|
LCM O.D (mm) |
270.37*159.79*2.70 |
|
LCM Luminance |
360 |
|
Signal Input |
eDP |
|
Signal Output |
HDMI |
|
PCB Outline |
150.0*80.0*1.6 |
|
Operating Temperature |
-10~+50℃ |
|
Storage Temperature |
-20~+60℃ |
|
Power |
12V/3A |
|
Touch Screen |
CTP |
|
TPM V.A (mm) |
257.12*145.00 |
|
TPM O.D (mm) |
303.12*191.00*5.05 |
|
TPM Luminance |
300 |
