3.95 Inch Square IPS Touch HDMI Smart Display with 420-Nit Brightness
LTK040FTHHM49-V0 is a 3.95-inch IPS TFT LCD touch display module featuring a 480×480 resolution, 420 cd/m² brightness, and wide viewing angles for clear and vivid image performance. Equipped with a capacitive touch panel (CTP), HDMI input, RGB output, and IIC touch interface, it offers convenient integration and responsive user interaction. Its compact design and reliable performance make it an ideal display solution for smart home devices and smart industrial applications.
- Product Details
|
Model number |
LTK040FTHHM49-V0 |
|
Size(inch) |
3.95 |
|
Resolution |
480*480 |
|
Viewing Angle |
IPS |
|
Luminance (cd/m²) |
420 |
|
Signal Input |
HDMI |
|
SignalOutput |
RGB |
|
Active Area(mm) |
71.86*71.86 |
|
Outline Dimension(mm) |
74.83*78.98*2.00 |
|
Touch Screen |
CTP |
|
TP Structure |
GFF |
|
TP Interface |
IIC |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
|
Power Supply |
12V/3A |
Get A Quote
If you are interested in our products and want to know more details. please leave a message here. we will reply you as soon as we can.
