5 inch 720*1280 UART TTL&232&485 Touch Screen Display
The LTK050HDHUT13-V0 is a 5.0-inch IPS display with 720×1280 resolution and 300 cd/m² brightness, offering vibrant visuals and wide viewing angles for smart home interfaces. Featuring a capacitive touch panel (CTP), it ensures responsive touch control for interactive devices. With RGB input and UART TTL/RS232/RS485 output, it supports flexible integration with home automation systems. The compact design and 1GB built-in flash (expandable) enable smooth UI performance. Operating in -10°C to +60°C, it's ideal for smart switches, control hubs, and embedded home terminals.
- Product Details
| Size（inch） | 5.0 |
|
Part Number |
LTK050HDHUT13-V0 |
|
Display Mode |
IPS |
|
Resolution |
720*1280 |
|
LCM A.A (mm) |
62.10*110.40 |
|
LCM O.D (mm) |
65.30*119.30*1.70 |
|
LCM Luminance |
300 |
|
Signal Input |
RGB |
|
Signal Output |
UART TTL&232&485 |
|
PCB Outline |
56.00*66.00 |
|
Operating Temp |
-10~+60℃ |
|
Storage Temp |
-20~+70℃ |
|
Power |
5V/2A |
|
Touch Screen |
CTP |
|
TPM V.A (mm) |
62.70*111.00 |
|
TPM O.D (mm) |
76.00*141.20*3.35 |
|
TPM Luminance |
260 |
| Flash |
1GB（support128Mbit~2*1GB) |
