15.6'' 1920*1080 IPS HDMI Signal TFT LCD Display Panel
This LTK156FHBHT01-V0 IPS LCD module has a high-resolution display of 1920*1080 pixels and a brightness of 200 cd/m². The active area is 344.16*193.59 mm and the overall size is 386.81*246.92*6.30 mm. Equipped with a capacitive touch screen (CTP), it can operate reliably in a temperature range of -0℃ to +50℃, and the storage condition is also -20℃ to +60℃. It is well suited for smart industrial environments, providing clear, high-quality visuals and reliable performance under various conditions.
- Product Details
|
Part Number |
LTK156FHBHT01-V0 |
|
Resolution |
1920*1080 |
|
Display Mode |
IPS |
|
LCM A.A (mm) |
344.16*193.59 |
|
LCM O.D (mm) |
350.66*205.25*3.20 |
|
LCM Luminance |
250 |
|
Signal Input |
eDP |
|
Signal Output |
HDMI |
|
PCB Outline |
150.0*80.0*1.6 |
|
Operating Temp |
-0~+50℃ |
|
Storage Temp |
-20~+60℃ |
| Power |
12V/3A |
|
Touch Screen |
CTP |
|
TPM V.A (mm) |
344.63*194.54 |
|
TPM O.D (mm) |
386.81*246.92*6.30 |
|
TPM Luminance |
200 |
Get A Quote
If you are interested in our products and want to know more details. please leave a message here. we will reply you as soon as we can.
