Leadtek 10.1 inch Smart Home Touch Display
Leadtek LTK101FHNCT19-V0 is a 10.1 inch capacitive touch display for smart home. The screen format is intended to support the 1200x1920 screen
and 16.7M colors. All input signals are MIPI 4 lane interface.
Features：
-
Size: 10.1inch
-
Interface Pin Connection: 40pins
-
Light Source: 32 white LED in 4S8P
-
CTP Structure: G+G+FPC+OCA
-
Operation voltage: 2.8V~3.3V
-
The cover hardness: 6H
-
This display is with a capacitive touch panel, it can support multiple touch.
Application：
Smart Home
General Specifications:
| Item | Specification |
| LCD Size | 10.1 |
| Panel Type | IPS |
| Resolution | 1200 x RGB x 1920 |
| Display Mode | Normally Black |
| Number of Colors | 16.7M |
| Viewing Direction | FULL |
| NTSC | 66% |
| Contrast Ratio | 1000 |
| Luminance | 300cd/㎡ |
| TP+LCM Module Size | 146.8 (W) x239.37(L) x4.23(H)mm |
| Panel Active Area | 135.36 (W) x 216.57 (L) |
| Pixel Pitch | 37.6 x 112.8 |
| Driver IC | OTA7290B+OTA7290B |
| Driver IC RAM Size | RAMLESS |
| Light Source | 32 white LED in 4S8P |
| Interface | MIPI 4Line |
| Drive IC | GT9271 |
| Construction | G+G |
| Surface Hardness | 6H |
| Operating Temperature | -20~+60℃ |
| Storage Temperature | -30~+70℃ |
| Transmittance: | ≥82％ |
To learn more about the product, please click on the video https://youtu.be/txqBTcQ2Q7Y
Once again, we thank you for your continuous support and trust in our company. Should you have any questions or require
further information, please do not hesitate to contact us.
