8.0 Inch Transflective TFT LCD Display for Industrial Handheld Devices
Welcome to Leadtek Display!
In industrial field operations, display visibility and touch responsiveness are essential for efficient and reliable performance. From outdoor construction sites and equipment inspections to factory maintenance and portable data collection, industrial handheld devices must adapt to changing lighting conditions and demanding working environments.
However, conventional LCD solutions may struggle with sunlight readability, wet-hand operation, or limited adaptability to industrial conditions, affecting usability during everyday fieldwork.
To address these challenges, Leadtek introduces the LTK080BFXCT36-V0, an 8.0-inch transflective TFT display module designed for industrial handheld tablets and outdoor equipment. Featuring 1200 × 1920 high resolution, transflective technology, and integrated capacitive touch, this module combines clear visuals with practical touch functionality for demanding industrial applications.
✨ Key Highlights
Combines reflective and transmissive display characteristics to improve readability under bright ambient light while maintaining backlight-assisted visibility in low-light environments. Suitable for both indoor and outdoor industrial applications.
Supports touchscreen operation with wet hands or gloves, providing greater flexibility for field inspections, equipment maintenance, and industrial applications where direct bare-finger interaction may not always be practical.
Features a G+G capacitive touchscreen with 10-point multi-touch support, enabling intuitive navigation and responsive interaction for industrial control interfaces and portable terminals.
Supports a convenient double-click wake-up function, allowing users to activate the display through a simple touch gesture for more efficient daily operation.
The portrait-oriented display provides sharp images and detailed visuals for equipment monitoring, technical data, inspection records, and graphical user interfaces.
Designed for industrial environments with an operating temperature range of -20°C to +70°C and a storage temperature range of -40°C to +80°C, supporting reliable operation across varying environmental conditions.
Basic Parameters
✅ LCD Size: 8.0 inch
✅ Module Number: LTK080BFXCT36-V0
✅ Resolution: 1200 × 1920
✅ Display Type: Transflective
✅ LCD Interface: MIPI
✅ Luminance: 369 cd/m²
✅ Reflectivity: 2.50%
✅ Viewing Angle: 60/60/60/60
✅ Color: 16.7M, Full Color
✅ Active Area: 108.00(W) × 172.80(H) mm
✅ Outline Dimension: 132.60(W) × 202.60(H) × 4.98(T) mm
✅ Touch Screen: CTP
✅ TP Structure: G+G
✅ TP Interface: I²C
✅ Power Consumption: 3170 mW
✅ Operating Temperature: -20°C to +70°C
✅ Storage Temperature: -40°C to +80°C
The LTK080BFXCT36-V0 is suitable for a range of industrial and outdoor applications:
— Industrial Handheld Tablets: Portable monitoring, data collection, and industrial control interfaces.
— Outdoor Inspection Terminals: Field inspection, infrastructure maintenance, and on-site reporting.
— Construction Site Equipment: Equipment monitoring, project tracking, and outdoor field operations.
— Industrial Data Collectors: Portable terminals for equipment information, measurement data, and inspection records.
Bringing Better Display Performance to Industrial Fieldwork
As industrial operations become increasingly mobile and data-driven, display modules must deliver more than basic visual output. Visibility under different lighting conditions, practical touch interaction, and environmental adaptability are becoming important considerations in handheld device development.
With its transflective display technology, high-resolution visuals, versatile touch functionality, and wide operating temperature range, the LTK080BFXCT36-V0 offers a display solution for industrial handheld devices operating across diverse environments.
Looking for a suitable display for your next industrial handheld project? Contact Leadtek to request samples, technical specifications, or discuss customization options.
▶Product Details: https://www.leadtekdisplay.com/80-transflective-ips-touch-display-p-3209.html
▶Product Showcase Video: https://youtu.be/MhXyAwvpCSc
