10.1" High-Brightness Portrait IPS TDDI Display Module for Visitor Management Machines

Welcome to Leadtek Display!

In smart industrial environments, display terminals must remain clear and responsive under challenging lighting conditions—from bright entrances and sunlit control rooms to fluorescent-lit production floors. Yet many solutions still struggle with poor outdoor readability, touch latency, or complex integration requirements that increase development time and system complexity.

Leadtek's new LTK101FTNIT78-V0 is designed to overcome these challenges. This 10.1" TFT module combines a high-brightness 500 cd/m² IPS display with an integrated touch-and-display driver architecture over a single MIPI interface, simplifying hardware design while delivering smooth touch performance. Featuring a portrait-oriented 1200 × 1920 resolution, it is ideal for smart industrial terminals.

Key Highlights
• 500 cd/m² brightness
Vivid visibility under factory floor lighting, lobby environments, and mixed indoor conditions.
• IPS full angle
± 80° horizontal and vertical viewing angle,readable from any operator posture or mounting position.
• 1200×1920 resolution
High pixel density (225 PPI) renders dashboards,forms, and process data with sharp precision.

• TDDI integration

Touch and display drivers combined in a single MIPI interface, reducing complexity and slimplifying FPC routing.

• Industrial-grade cover glass
Asahi tempered glass with CS >450 MPa, hardness ≥6H, and AF anti-fingerprint coating.

• Wide operating temperature

-10°C to +60°C operating, -20°C to +70°C storage. Tested across thermal shock cycles.

Basic Parameters

✅LCD Size: 10.1 inch
✅Module Number:LTK101FTNIT78-V0
✅Resolution: 1200*1920
✅LCD Interface: MIPI_TDDI
✅Luminance(cd/m²): 500
✅Viewing Direction: IPS
✅Active Area(mm): 135.36(H)*216.58(V)
✅Outline Dimension(mm): 148.80(H)*239.37(V)*3.58(T)
✅Touch Screen: NA
✅TP Structure: NA
✅TP Interface: IIC
✅Operating Temp: -10~+60°C
✅Storage Temp: -20~+70°C

Applications:Smart Industry
— Visitor management
— Industrial tablet computers
— MES systems

If your next project calls for a high-luminance, portrait-native TDDI display with industrial grade reliability,now is the time to get one on your bench.Don't design around limitations.

Product Showcase Video: https://youtu.be/sTxISR5WzMs

Product Details: https://www.leadtekdisplay.com/101-inch-500nits-portrait-ips-tddi-tft-lcd-display-p-3193.html
