Leadtek’s Deep Customization Capabilities in Display Solutions - Part 7: PCBA Customization
In the era of ubiquitous connectivity and intelligent upgrades, the performance and reliability of the hardware's "brain" – the core printed circuit board assembly (PCBA) – are paramount. As a manufacturer in providing end-to-end display and electronic solutions, Leadtek's professional PCBA customization solutions are available to global clients. This service is designed to provide comprehensive circuit support for various smart hardware, from signal conversion and audio-video processing to system integration, connecting limitless possibilities for innovation.
Core Business Segments: Precision-Matching for Diverse Scenario Requirements
Leadtek's PCBA customization service addresses industry-specific pain points and is divided into three core business segments, ensuring each circuit board precisely empowers the end product.
1. Interface Adapter Boards: Opening High-Speed Channels for Display Signals
• Core Function: Professional support for bidirectional or unidirectional conversion between various display interface protocols, including RGB, LVDS, eDP, and MIPI.• Performance Highlights: Supports lossless transmission of 4K ultra-high-definition signals with end-to-end latency of less than 1 millisecond, achieving real-time screen synchronization.
• Customer Value: Features a modular "plug-and-play" design with strong compatibility, significantly reducing integration cycles and development complexity for customers' display modules.
2. Audio-Video Transmission Solutions: Creating Immersive Audiovisual Experiences
• HDMI Processing Board: Comprehensive support for HDMI 2.0/2.1 protocols, enabling 4K@60Hz high refresh rate output. Onboard enhanced ESD protection circuits ensure long-term interface stability.• AV Video Board: Optimized for processing traditional analog video signals like CVBS and YUV. Employs unique anti-interference design and signal enhancement technology, enabling stable transmission distances of up to 100 meters in complex electromagnetic environments, meeting professional needs such as security surveillance and long-distance broadcasting.
3. Industrial Control Core Boards: Building a Reliable Foundation for Industrial Applications
• Serial Communication Board: Full support for the complete range of serial communication protocols including RS232, RS485, and TTL. Built-in opto-isolation protection and industrial-grade EMC design effectively guard against surges, lightning strikes, and ground loop interference, ensuring absolute reliability for industrial field communications.
• Android Core Board: Offers multiple high-performance processor options from quad-core to octa-core. Comes pre-installed with a clean Android system and provides open underlying driver interfaces and rich GPIOs, offering a powerful and flexible hardware platform for secondary development and functional customization of customer products.
The Leadtek Advantage: Full-Cycle Assurance from Blueprint to Mass Production
Choosing Leadtek means opting for a comprehensive, reliable, and efficient PCBA partnership model.
• Integrated Delivery: We provide full-process services from schematic design, PCB layout, component procurement, SMT assembly, to program burning and functional testing. Customers simply present their requirements and can receive a mature PCBA module ready for direct installation.• Military-Grade Quality Control: Production lines adhere to the ISO9001 quality management system, incorporating stringent procedures such as AOI (Automated Optical Inspection), X-Ray inspection, and high-temperature aging tests, ensuring every delivered circuit board meets high precision and high reliability standards.
• Agile Response & Cost Optimization: Leveraging a mature supply chain and an extensive design database, we can quickly match customers with the optimal solution, effectively controlling costs while guaranteeing performance, thereby accelerating time-to-market.
"In the chain of smart hardware innovation, the PCBA is the physical carrier of all functional logic. Our goal is to become a product partner for our clients. Through our professional PCBA customization solutions, customers can focus more energy on product definition and market expansion, entrusting the complex circuit implementation to us with confidence, jointly 'connecting unlimited possibilities'."
Start Your Customization Project
Whether you are developing a new generation of intelligent display devices, industrial control terminals, or innovative audio-video systems, Leadtek's PCBA team is ready to provide professional technical consultation and project support.
Contact Sales: [ sales@leadtekdisplay.com ]
Learn More: [ www.leadtekdisplay.com ]
