Leadtek New Product Introducing - 4.2 inch 300x400 SPI Interface Paper Display

Prev Views: 486 Update date: Dec 07,2023 Next

LTK042MNHLM15-V0 is a RBW active matrix thin film transistor liquid crystal display that uses amorphous silicon TFT as a switching device.


It is a reflective type display operating in the total reflection. This TFT LCD has a 4.2 inch diagonally measured active display area with 300 RW horizontal by 400 vertical pixel resolution.


Features:

  • 4.2 inch configuration
  • RBW by 2 Grey signal input
  • RoHS Compliance & Halogen Free



Application:

  • Parking Lot Meters
  • Timers
  • Stopwatches
  • Instruments
  • Electronic Price Tags
  • Outdoor Wearables
  • Outdoor Handheld Products




Comparison of technical parameters between PAPER DISPLAY and normal TFT display under the same conditions:

Category

Normal TFT Display

Leadtek LTK042MNHLM15-V0

Power Consumption

≈1152mW

≈O.1mW

Application

Cannot be viewed under strong light

The stronger the external light, the clearer the display

Heating

Double-core lamp/heating phenomenon

No backlight/no heat dissipation

Is it eye protection?

No/With Blu-ray

Yes/No Blu-ray


BASIC PARAMETERS:

Module No: LTK042MNHLM15-V0
LCDSize:  4.2 inch
Resolution:  300x400
Display Mode:  Normally White/Reflective
Interface:  SPI
Outline Dimension:  67.60(H) x 91.00(V) x 0.72(T) (Typ.)
Display Area:  63.90(H)x84.80(V)
Operating Temperature:  -20°C ~+70°C
Storage Temperature:  -30°C ~+80°C

To learn more about the product, please click on the video  https://youtu.be/cH6mDTz3-mo

Once again, we thank you for your continuous support and trust in our company. Should you have any questions or require further information, please do not hesitate to contact us.
