Leadtek 7 inch IPS MIPI TOUCH DISPLAY

LTK070P3078W-06KC-V0 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous

silicon TFT as a switching device. This model is composed of a TFT LCD panel, driving circuit and a capacitive touch panel.

This TFT LCD has a 7.0 (16:9) inch diagonally measured active display area with 1024 horizontal by 600 vertical pixel resolution.

Features：

• 7 inch 16:9 diagonal inch configuration

• Resolution: 1024x600

• Interface: MIPI

• Display Mode: Normally Black

• Compatible with NTSC & PAL system

• Image Reversion: UP/DOWN and LEFT/RIGHT

• LCM Brightness：200cd/㎡(TYP),uniformity≥80%

• OPERATING TEMP: -10°C~ +50°C

• STORAGE TEMP: -20°C~ +60°C

• ROHS design

Application：

Smart Home

BASIC PARAMETERS：

• Module No: LTK070P3078W-06KC-V0

• LCD Size: 7.0 inch TFT

• Resolution: 1024xRGBx600

• LCD Viewing Direction: ALL

• Display mode: Normally Black

• LCM Brightness：200cd/㎡(TYP),uniformity≥80%

• Outline Dimension: 164.50(H) x 99.60 (V) x4.52(D) mm

• Display area: 154.21 (H) x 85.92 (V) mm

• Number of Pixel: 1024 (H) x3(RGB)x 600 (V) pixels

• Pixel pitch: 0.1506 (H) x3(RGB)x 0.1432 (V)s mm

• Pixel arrangement: RGB Vertical stripe

• Backlight: White LED

• Interface: MIPI

• OPERATING TEMP: -10°C~ +50°C

• STORAGE TEMP: -20°C~ +60°C
