Leadtek 5 inch Smart Home Touch Display

Features：

• Size: 5 inch configuration

• Resolution: 800x480

• Display mode: Normally Black

• Viewing Direction: ALL

• CTP type: G+G

• Interface: 24bit RGB

• Back Light: 12pcs White LED

Application：

Smart Home

Leadtek LCD display offering unparalleled clarity, color saturation, and visual comfort. We adopt strict quality control to ensure

stable operation and long service life for each unit. We understand your requirements for product quality, and therefore,

we always be customer-oriented, continuously improving the quality and reliability of our products.

BASIC PARAMETERS：

• Module No: LTK050WVBCT18-V1

• LCD Size: 5 inch

• Dot arrangement: 800(RGB)×480

• Color filter array: RGB vertical stripe

• Display mode: Normally Black

• Viewing Direction: ALL

• CTP type: G+G

• Surface hardness: 6H

• CTP Driver IC: FT5426

• LCM+CTP Outline Dimension: 143.60(W)×95.70(H)×4.60(T) mm

• Active area: 108.00(W)×64.80(H) mm

• Dot pitch: 0.08625(H) x 0.08625(V)

• Interface: 24bit RGB

• Operating temperature: -20 ~ +70 ℃

• Storage temperature: -30 ~ +80 ℃

• Back Light: 12pcs White LED

• LCM Brightness：400cd/㎡(TYP)

• LCM+CTP Brightness：350cd/㎡(TYP)
