Leadtek 4.3 inch IPS Touch Panel Display

 Leadtek LTK043WVHCT26-V0 is a 1000nits high brightness TFT LCD touch module designed for smart medical, LCD viewing

direction ALL, people could see the quality display image from any angle.The material is RoHS compliant.

Features：

• Size: 4.3 inch landscape

• Resolution: 800x480

• Display mode: Normally Black

• LCM Brightness：1200cd/㎡(TYP)

• LCM+CTP Brightness:1000cd/㎡(TYP),Uniformity≥80%

• Working voltage: 3.3V, control card: FT5206

• CTP Structure: P+G

• Interface: RGB

Application：

Smart Medical

BASIC PARAMETERS：

Module No: LTK043WVHCT26-V0

Panel Type: IPS

Number of Colors: 16.7M

Viewing Direction: ALL

CTP+LCM Module Size: 105.10(H) ×66.98(V)×4.50(T) mm

Panel Active Area: 95.04 (H) × 53.86(V) mm

Pixel Pitch: 0.1188 (W) x 0.1122 (H)

Working voltage: 3.3V, control card: FT5206

Light transmittance: ≥85%

Surface hardness: 6H

Operating Temperature:-20℃~ +70℃

Storage Temperature:-30℃~ +80℃

Requirements on Environmental Protection: ROHS
