Leadtek 4 inch 480x800 Portrait IPS TFT Screen
LTK040WVBLM10-V0 is a color active matrix TFT-LCD (Thin Film Transistor Liquid Crystal Display) module that uses
amorphous silicon TFT as a switching device. This module is composed of LCD panel, driver IC and LED backlight.
Features：
-
3.97 inch configuration
-
Wide Viewing Angle
-
RoHS Compliance & Halogen Free
-
Support customization
Application：
Laboratory Equipment
Leadtek is dedicated to the research and development, manufacturing and distribution of LCD Screens, touchscreens and comprehensive display solutions,
our products adopt strict quality control to ensure stable operation and long service life for each unit. We understand your requirements for product quality,
and therefore, we will always be customer-oriented, continuously improving the quality and reliability of our products.
General Description
| Item | Specification | Unit |
| LCD Size | TFT"3.97 | inch |
| Panel Type | IPS | - |
| Resolution | 480 x RGB x 800 | - |
| Display mode | Normally Black | - |
| Display colors | 16.7M | - |
| Viewing Direction | ALL | - |
| Contrast Ratio | 800 | - |
| Luminance | 300 | nit |
| Module Size | 56.34 (W) x95.70(L) x2.0(T) | mm |
| Panel Active Area | 51.84 (W) x 86.40 (L) | mm |
| Pixel Pitch | 0.108(H) × 0.108(V) | mm |
| Driver IC | ST7701S-G5 | - |
| Light Source | 8 white LED | - |
| Interface | MIPI | - |
| Operating Temperature | -20~+70 | ℃ |
| Storage Temperature | -30~+80 | ℃ |
To learn more about the product, please click on the video https://youtu.be/mH3GAzhS2DM
further information, please do not hesitate to contact us.
