Leadtek 1.54 inch 240x240 Capacitive Touch Panel Display for Smart Industry
Features：
-
Shape: Square
-
1.54 inch TFT with 240x240 Resolution
-
FPC: 15PINS
-
SPI Interface
-
Viewing direction: ALL
-
LCM Brightness:400cd/㎡(TYP)
-
TP Structure: G+F, single point touch, IC:CST716, material 0.7mm Asahi
Application：
Smart Industry
General Information:
|
Module No: |
LTK015QVBCT01-V0 |
|
Screen Size: |
1.54 inch |
|
Driver element: |
TFT active matrix |
|
Viewing direction: |
IPS |
|
CTP+LCM Module Size: |
35.70(H) x 39.70 (V) x3.15(D) mm |
|
Panel Active Area: |
27.72 (H) x 27.72 (V) mm |
|
Touch Panel View Area: |
28.22（H）x 28.22(V) mm |
|
Number of Dots: |
240(RGB)x240 |
|
Driver IC: |
ST7789V2 |
|
Colors: |
262K |
|
Interface: |
SPI |
|
Backlight Type: |
white LED |
|
Operating Temperature: |
-10℃~ +60℃ |
|
Storage Temperature: |
-20℃~ +70℃ |
|
Environmental Protection: |
ROHS |
To learn more about the product, please click on the video https://youtu.be/htRxawBdM4g
