Custom tft lcd 5 inch touch screen, 720*1280 ips panel

LTK050H3146W-08QC-V3 is a transmissive type color active matrix TFT(Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This module is composed of a TFT LCD module, a driver circuit, and a back-light unit.The resolution of a 5” contains 720*1280dots.

お問い合わせはこちら

戻る前へ次へ

製品詳細

Model Number	LTK050H3146W-08QC-V3
Size（inch)	5''
Display model	IPS
Resolution	720(H)*1280 (V)
Interface	MIPI
LCD OD (mm)	76(H)140.8(V)3.35(D)
Active area (mm)	62.1(H)*110.4 (V)
Brightness	260
Touch screen	CTP
Touch screen structure	CG
Touch screen IC model	GT911
Touch screenInterface	IIC
Operating Temp	-10~+60℃
Storage Temp	-20~+70℃
