5.0 inch TFT LCD RGB interface Capacitive touch panel 480 x 272 display 200 nits TN panel
LTK50G23-40TB-A3 is a 5.0” (5.0'' diagonal) TFT Liquid Crystal Display NB module with LED Backlight unit and 30 pins eDP interface. This module supports 480x272 FHD mode. (C)
- Product Details
Display Type: | 5.0''TFT, NORMAL White |
Module PN#: | LTK50G23-40TB-A3 |
View direction: | 6 o'clock |
Brightness: | 200 nits |
Operating temperature: | -20℃ ~ +70℃ |
Storage temperature: |
-30℃ ~ +80℃ |
