3.5inch Module 320xRGBx240 with RGB interface TFT display
LTK035QC54HYL is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving circuit and a back light system. This TFTLCD has a 3.5 inch diagonally
measured active display area with Full HD (320 horizontal by 240 vertical pixel) resolution.(E)
- Product Details
|
Model Number |
LTK035QC54HYL |
|
Size |
3.5'' |
|
Resolution |
320xRGBx240 |
|
Interface |
RGB |
|
Outline dimension (mm) |
76.9x63.9x3.20 |
|
Active area (mm) |
70.08(H)x52.56V) |
|
Brightness |
320 |
|
Display model |
IPS |
