1.3inch Module 240(RGB)X240 with SPI 4line or MCU interface TFT display
1. DISPLAY TYPE:1.3"TFT,TRANSMISSIVE
2. DRIVER IC: ST7789V
3. VIEWING DIRECTION: All
4. OPERATING TEMPERATURE:-20°C-+70°C.
5. STORAGE TEMPERATURE:-30°C-+80°C.
6. BACKLIGHT TYPE: 2 WHITE LEDS.
7. LED:If=20.0mA/LED (CONSTANT CURRENT).
8. REFERENCE DIMENSION.
2. DRIVER IC: ST7789V
3. VIEWING DIRECTION: All
4. OPERATING TEMPERATURE:-20°C-+70°C.
5. STORAGE TEMPERATURE:-30°C-+80°C.
6. BACKLIGHT TYPE: 2 WHITE LEDS.
7. LED:If=20.0mA/LED (CONSTANT CURRENT).
8. REFERENCE DIMENSION.
9. ICON MEAN CRITICAL DIM
10. MUST MEET THE REQUIREMENT OF ROHS
(E)
- Product Details
|
Model Number |
LTK013HW24A1R |
|
Size |
1.3" |
|
Resolution |
240(RGB)X240 |
|
Interface |
SPI 4line or MCU |
|
Outline dimension (mm) |
26.85(H)X29.55(V)X1.5 |
|
Active area (mm |
23.4(H)X23.4(V) |
| Brightness | 350 |
|
Display model |
IPs |
