12.1 Inch 1280*800 High Brightness TFT LCD for Smart Medical

Welcome to Leadtek! Today we introduce the new self-developed products, 12.1-inch 1280x800 TFT LCD display, expertly crafted for smart medical.

It offers exceptional resolution of 1280*800, highbrightness of 750 cd/m² and wide viewing angles.It also can operates in -20°C to +70°C,meeting the rigorous demands of today’s advanced medical technologies. This display solution is designed to enhance user experience and reliability in a wide range of smart medical devices, including patient monitors, diagnostic equipment, portable medical instruments, and more.

Features:

-High Resolution: 1280×800 ensures clear medical data and monitoring visuals.

-IPS Viewing Angle: Provides excellent clarity from various angles.

-High Brightness: Maintains visibility even in bright environments.

-Wide Temperature Range:Suitable for diverse medical conditions.

-Seamless Integration:LVDS interface easily integrates with existing medical devices.

Application: Smart Medical

BASIC PARAMETERS:

✅LCD Size:12.10 inch

✅ModuleNumber：LTK121WXBLM13-V0

✅Resolution:1280*800

✅Viewing Angle:85/85/85/85(IPS)

✅Luminance(cd/m2):750

✅LCM Interface:LVDS

✅Active Area(mm):261.12*163.20

✅LCM Module Size(mm):278.00*184.00*6.63

✅Operating Temp:－20~＋70°C

✅Storage Temp:－30~＋80°C

Unlock the future of medical technology with Leadtek–where innovation meets precision.

If you want to know more about this product, please leave a message or contact us.

To learn more about the product, please click on the video: https://youtu.be/OWYObCs4bCg
