5 inch TFT LCD 480x854 MIPI interface with Capacitive touch panel
LTK050B4050T-CT color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel and a driving circuit.
This TFT LCD has a 5.0 inch diagonally measured active display area with (720 horizontal by 1280 vertical
pixel) resolution. (C)
- Product Details
|
Model Number |
LTK050B4050T-CT |
|
Size |
5.0'' |
|
Display model |
IPS |
|
Resolution |
480x854 |
|
Interface |
MIPI |
|
Outline dimension (mm) |
83.8x137.8x3.6 |
|
Active area (mm) |
62.16x110.1 |
|
Brightness (nits) |
350 |
| Operating temperature | -10℃ ~ +60℃ |
| Storage temperature |
-20℃ ~ +70℃ |
