4.3 inch 800*480 TFT LCD with 24 bit RGB interface IPS display mode
This display module is a transmissive type color active matrix TFT(Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This module is composed of a TFT LCD module, a driver circuit, and a back-light unit.The resolution of a 4.3” contains 800(RGB)X480 dots.(W)
- Product Details
|
Model: |
LTK043B4020T-CTP |
|
Size: |
4.3'' |
|
Cell Type: |
IPS |
|
Resolution: |
800*480 |
|
Interface: |
RGB |
|
Outline Dimension: |
105.5*67.2*3.375(mm) |
|
Active Area: |
95.04*53.78(mm) |
