5.48inch with 1080x1920 resolution 1080x1920 interface display module
LTK0548A3901R is a monochrome OLED display module with 1080x1920 dot matrix. The characteristicsof this display module are high brightness, self-emission, high contrast ratio, slim/thin outline,
wide viewing angle,wide temperature range, and low power consumption.
- Product Details
|
Size
|
5.48'' |
| Number |
LTK0548A3901R |
|
Resolution
|
1080x1920 |
|
Interface
|
MIPI 4LANE |
|
Module Outline Dimension
|
70.356x127.344x0.643 |
|
Active Area
|
68.256x121.344 |
|
Display Mode
|
AMOLEE
|
|
Driver IC
|
RM67198
|
|
Touch IC
|
CST148
|
