TFT LCM Display 4.3inch, TFT High Brightness 4.3inch Display
1. DISPLAY TYPE:4.3 INCH TFT /TRANSMISSIVE
2. BACKLIGHT:16 CHIP WHITE LED, IN PARALLEL
3. OPERATING TEMP: -20°C~+70°C
4. STORAGE TEMP: -30°c~+80°c
5. RESOLUTION: 480xRGBx272
6. LCD IC: ST7282G4
7.RoHS Compliant
2. BACKLIGHT:16 CHIP WHITE LED, IN PARALLEL
3. OPERATING TEMP: -20°C~+70°C
4. STORAGE TEMP: -30°c~+80°c
5. RESOLUTION: 480xRGBx272
6. LCD IC: ST7282G4
7.RoHS Compliant
- Product Details
| Model No: |
LTK043A40A2HX |
| Size: | 4.3inch |
| Cell Type: | TN |
| Resolution: | 480X272 |
| Interface: | RGB 24bit |
| Outline Dimension: |
105.5X61.4X3mm |
| Active Area: |
95.04X53.86mm |
| Brightness: | 1300nits |
| With/Without TP: | Without TP |
| LCD driver IC: |
ST7282G4 |
